PFA 6K Dual 1350W Channels Digital power amplifier

Description

Model PFA6K
Outputs Stages
8Ω EIA 1 kHz 1% THD 1350Wx2
4Ω EIA 1 kHz 1% THD 2000Wx2
BRIDGE POWER(8Ω) 4000Wx1
OUTPUT POWER, BRIDGE MONO MODE
Typical Distortion
8 ohms 0.02%
Maximum Distortion <2% Frequency Response (8 ohms) 20-20KHZ Noise (20 Hz-20 kHz, 32 dB Gain) <1mv Damping Factor (8 ohms) 500 Output Circuitry CLASS-D The Function for Color Screen 1.The Working Voltage,Currency,Temperature,and the impedance for each channel,operating Rower. 2.Operation level for each channel; 3.Choosing the working mode; 4.High-Pass Filter: 5.Impedance Matching switchover; 6.With the muting switch Input Sensitivity 1v Maximum Gain (1.2V setting) 36dB Maximum Input Level 26dB AC Power Requirements 85V-265V Size W: 483 mm , D: 385 mm,H: 88 mm
