Bill 6 system

Description

Model Bill-6
Type 6.5” line array active system
Freq. Response (-10dB) 100 Hz-20k Hz
Sensitivity 1W@1M 98 dB
Power Output(RMS) 80 watts
Nominal Impedance 4 ohms
LH 6.5” woofer, 1” VC, 22 OZ
HF 5*1” tweeter, Neodymium
Amplifier Class-D
Controls On/ off switch, Rotary/ push
Line input connectors 1*Combo(XLR/ Jack)
Line output connectors
1*XLR
DSP 96K HZ 48 Bit Sampling frequency DSP Processor
Power supply 230 V AC, 50 Hz
Cabinet material PP+glass fiber
Cabinet surface Powder coating
Dimensions(mm) 190*220*225
